Description

Type: Digital Audio Processor (Bass Enhancer)
Maximum Input Level: 15V RMS
Maximum Output Level: 13.5V peak
Frequency Response: 10 Hz – 100 kHz; ±1 dB
Total Harmonic Distortion (THD): 0.003%
Signal-to-Noise Ratio (SNR): 130 dB
Balanced Input Noise Rejection: 60 dB
Input Impedance: 10 kΩ
Output Impedance: 150 Ω
Power Supply Voltage: 12.5 – 14.5V
Recommended Fuse Rating: 1A
